1.Introduction

The introductions of popular books on T_EX and especially L^AT_EX usually start with a celebration of the benefits of structured documents and generic markup. In this context, L^AT_EX is often compared to wysiwyg (what you see is what you get) text editors, which are claimed to concentrate only on visual design and not logical design. See for instance section 1.5 of Lamport's book on L^AT_EX for some widely accepted reasons why not to use wysiwyg editors.

In the past decade the empirical observation that it was difficult to write well structured documents with wysiwyg editors has made place for a doctrine that such a thing would be impossible. Many people adopted textual ASCII-based text editors like Emacs or Vi as a religion and claim that such editors would be the sole in which a structured text — a program — can be correctly visualized.

On the other hand, if systems like T_EX and L^AT_EX are so much better than wysiwyg editors, why is it so that most people are still reluctant to learn T_EX or L^AT_EX, and why do wysiwyg editors still dominate the market?

When we started to develop T_EX_MACS about four years ago, our main design aim was to solve this paradox, by creating a wysiwyg and structured technical text editor. The current version of T_EX_MACS can be downloaded from

www.texmacs.org

In order to design T_EX_MACS, we first had to analyze the reasons why the wysiwyg editors from then were inadequate for the creation of structured documents. These reasons, which are often of a psychological order, will be studied in section 2. In a second stage, we observed that these problems were not inherent to wysiwyg editors, and we removed them by developing new editing techniques. These techniques will be presented in section 3.

Currently, T_EX_MACS is much more as just a technical text editor. For instance, it is possible to interface the program with several computer algebra systems. As its name suggests, T_EX_MACS has also been inspired by that Emacs editor. For instance, it supports the Guile/Scheme extension language. In section 4, we will shortly describe some of these additional features.

In section 5, we conclude with the prediction that structured wysiwyg editors will become very common within five years. Nevertheless, an important question is how this will happen, and whether some important lessons from the past will be retained.

2.Analyzing technical typesetting systems

2.1.Drawbacks of classical wysiwyg editors

When comparing classical wysiwyg editors with T_EX or L^AT_EX, the following drawbacks are often heard or implicitly felt:

Lack of primitives for creating structured text

Bad visualization of structured text

Wysiwyg editors incite visual typesetting

Difficulties to create structured text

Wysiwyg editors are complex and slow

Bad document formats

2.2.Towards criteria for analyzing the quality of text editors

The drawbacks we have mentioned are actually related to a certain number of criteria, which may be used to analyze the quality of a text editor or an electronic typesetting system. Again, we made up a non exhaustive list of possible such criteria. In order to be fair, we now also included a certain number of criteria which plead in favor of wysiwyg editors.

Support of structural markup

Primitives

Support of some fixed primitives for structural markup, as in HTML.

Extendibility

Support of a macro expansion system to create new primitives and style files.

User friendlyness

Simplicity

The system should be sufficiently simple to use. This implies that the user interface should be standard, that the basic editing primitives should have a clear meaning, etc.

Comfort

The system should be comfortable to use. This implies for instance that the editor should have a high reactivity, that is a fast response to user events. By preference, it should not be necessary to manually rerun a typesetting engine after each modification. The readability of text on the screen is also an important and underestimated factor, which may avoid headaches and such. More generally, one should strive for maximal ergonomics.

Distraction

Just like a well typeset document allows the reader to concentrate himself on reading the actual content of a document (and not be distracted by typesetting issues), a good editor should allow the user to concentrate on the actual document (and not be distracted by programming issues and such). One main advantage of using an editor like T_EX_MACS is that you can do mathematics while typing a text.

Documentation

Well documented programs help the user to progress, whatever his level, and in any direction. It is preferable that the documentation comes with the program itself and that the program is self documenting (for instance, you learn about appropriate keyboard shorthands when using the menus).

Adequacy

Controlability

In the worst case, a program provides certain features which are so difficult to exploit that they become useless. This may for instance be the result of an inadequate user interface. Document formatters like T_EX provide full control because of there textual document format. Yet, their controllability is not always optimal: think about inserting a new column in a complex table.

Faithfulness

It is also important that the user of a program obtains the result he expects. From this point of view, the wysiwyg-ness of an editor is an advantage.

Transparency

In order to have full control over a program, the user needs to understand at each moment what is going on. In particular, the structure of the document should be transparent for the user. In the case of a text formatter, this is ensured by the fact that you explicitly see all structural markup. In the case of a wysiwyg editor, one needs other mechanisms to ensure transparency.

Quality of the endproducts

Document format

Readability

It is preferable to use a text based document format, so that the documents may in principle be edited by hand.

Simplicity

If the document format is also sufficiently simple, than it will indeed be able to edit documents by hand. Simplicity also makes it easier to write converters to other formats.

Comptability

If possible, one should opt for a format which already exists, or which is a particular case, an extension, or a modification of an existing format.

Permanence

The document format should not change in a predictable way and not to much from one version of the program to another.

Evolutivity

Freedom

http://www.gnu.org/philosophy/free-sw.html

The freedom of software is essential for its development in a scientific way, as has been the case for a system like T_EX. It favorites for instance the evolutivity and the accessibility of the software and the readability and permanence of the data format.

3.Techniques for structured wysiwyg editing

In this section we discuss several new techniques, which have been implemented in T_EX_MACS in order to fulfill the criteria stated in the previous section. We focus on the techniques related to structured wysiwyg editing, without striving for exhaustion.

3.1.Structural markup

In order to implement structural markup, one first has to analyze the different types of structural markup that may occur. We have already distinguished between editors which provide a limited set of basic primitives like the strong tag in HTML and editors which enable the user to define his own macros.

A second distinction concerns the nature of the structural markup during typesetting. Simple structural markup, like the above strong tag, only locally affects the typesetter. More complicated markup, like an enumeration tag, may necessitate all text after the tag to be retypeset each time we modify it. Changes in the most complicated forms of structural markup, like references or fields of a spreadsheet, may require the whole document to be retypeset.

A third distinction concerns the level of interactivity of the structural markup. In the case of complex markup like references or tables of contents, it is reasonable to perform the necessary recomputations on explicit request of the user. For computational markup, like Java scripts, it is reasonable to implement a mechanism to deactivate and reactivate the markup. For simpler markup, like the strong tag, it is nice if the arguments of the macro can be modified in a more direct way.

Currently, T_EX_MACS supports all of the above mechanisms. Likewise T_EX, the editor transforms the logical source tree into a physical box tree. However, in our case, the boxes contain much more information. In particular, whenever possible, they contain the location of the corresponding code in the source tree. More details about this correspondence can be found in the help about the implementation of T_EX_MACS.

As to user macros, we both provide real macros and lambda expressions. When expanding a macro, the arguments of the expansion can be modified interactively by the user. For instance, the L^AT_EX \section command is a macro in T_EX_MACS. From the technical point of view, the typesetter remembers the source locations of the arguments of the macro expansion, which are necessary to associate source locations to the final boxes.

In older versions of T_EX_MACS, we only provided lambda expressions for the creation of user macros. The applications of lambda expressions have first to be disactivated, before they can be edited, and reactivated as soon as you are done. Lambda expressions are still implemented in order to support computational markup like increasing a section number.

Remark 1. It is also interesting to analyze the difference between T_EX/L^AT_EX and XML from the point of view of structural markup. Indeed, a T_EX document is very sequential in nature, because it is close to a program. An XML document is much closer to a tree, which may be traversed in parallel. One typical consequence of this difference is that, from the XML point of view, something like a table of contents is generated by a piece of an XSL style file which is independent from the sectional macros. On the one hand this independence is attractive; on the other hand the approach is less “object oriented” and breaks the “orthogonality”. For instance, a new user-provided sectional macro based on a standard sectional macro will not be taken into account when generating a table of contents.

3.2.Efficiency of the typesetter

One major problem of wysiwyg (structured) editors is speed, although the constant improvement of CPU's plays in favor of such editors. The two main sources of difficulty are the speed of the typesetter and the speed of displaying typeset text. As a main objective, the required reactivity of the editor (i.e. the response time to user input), should be small with respect to the typical time between two keyboard hits.

In order to reduce the typesetting time, our main approach is to retypeset a minimal amount of text at each modification. For the simplicity of the design of the typesetter, we have nevertheless decided to retypeset the whole paragraph whenever a part of needs to be retypeset. This is reasonable, because it will at least be necessary to recompute all line-breaks; this recomputation usually necessitates a time which is proportional to retypesetting the whole paragraph.

The more complicated question is how to predict which paragraphs have to be retypeset, especially in presence of dynamic environment variables like section numbers. Our algorithm is as follows: we need to retypeset at least all paragraphs where a change occurred. For each paragraph we also remember all changes of the environment variables (like counters of section numbers) before and after the paragraph. When retypesetting a succession of paragraphs, we compare the new changes with the former changes. If the changes remain the same, then it is not necessary to retypeset the subsequent paragraphs.

Our strategy may be refined in the future in two ways. First of all, even when some environment variables change, it is only necessary to retypeset the paragraphs which effectively involve these variables. Secondly, one might decide to only retypeset the document up to those paragraphs which are visible on the screen.

As to the speed of redisplaying modified text, we apply the classical strategy of using a second invisible screen buffer in order to reduce flickering: when the whole text has been redisplayed, the second screen is copied to the visible screen. Actually, we start by redisplaying the text which is closest to the cursor and end with the text which is the farthest away. Whenever a keyboard event or a mouse click occurs, redisplaying is interrupted and only the available text is copied from the second screen to the visible screen. This allows the user to see the updated text close to the cursor in the case when he types very quickly.

3.3.User interface

A less complicated, yet very important issue is how the user may create structural markup. In the design of the T_EX_MACS user interface, we have followed the principle of redundancy: some users prefer toolbars or menus, others prefer to use the keyboard. For instance, a fraction can be obtained in the following ways:

1. By pushing the “fraction icon”.

2. Via the “Insert” menu.

3. By typing the T_EX_MACS keystrokes Escape F.

4. By typing the T_EX command \frac and pressing Enter.

Furthermore, T_EX_MACS attempts to teach users about these alternative ways via messages on the footer and help balloons. In this way a user can start by exploring the possibilities of T_EX_MACS via the menus. As soon as he often needs a certain feature, he will naturally learn a keyboard shorthand for using this feature in a more efficient way.

Actually, the T_EX_MACS user interface provides several additional tricks to maximize the user's efficiency in entering texts. For instance, in order to obtain the mathematical symbol , it suffices to type Alter-a. In order to obtain , or , you may use the keystrokes - >, @ +, resp. < | =. The combination of these tricks and the self documenting properties of the user interface make it very simple and efficient to learn and use T_EX_MACS, in comparison with more classical programs like T_EX and L^AT_EX.

In order to obtain a well structured document as an endproduct, we already mentioned the fact that a good editor should encourage the user to structure his work. In T_EX_MACS this is accomplished by suggesting the reader to first choose a document style (without which he will not be able to do much), or by choosing one for him. Next, the user interface naturally depends on the chosen document style and on the editing mode (math mode, preamble, etc.). Furthermore, structural markup is always put in a prominent place.

A more complicated problem, which has not completely been (and probably never will be) solved is the standardization of structural markup. One indeed has to be careful not to provide a too abundant number of macros in new styles: this may result in the users getting lost, so that they will prefer to fall back to more visual markup.

3.4.Transparency and controllability

Another interesting question is how to make the structure of a document transparent inside a wysiwyg editor and how to give the user full control over this structure. This question is mainly a psychological one: the user has to feel the structure in a way which is closest to his mental representation and he has to have the impression that he has optimal control over his document.

From our point of view, showing an ASCII text which represents the document in coded form is not necessarily optimal for both of these purposes. Indeed, an expression like

\frac{1}{\alpha_1+\frac{1}{\alpha_2+\frac{1}{alpha_3+\ddots}}}

is not clearer from a structural point of view than its graphical representation

Similarly, the user does not necessarily have optimal control: what about inserting a new column in a complex T_EX table?

Of course, there are also examples where the structure of the document is a priori more transparent and controllable in its coded form. A good example is the piece of L^AT_EX code

Some \textbf{\red{bold blue}} text.

In a wysiwyg editor, it is not clear whether the text “bold blue” is bold and blue or blue and bold. Furthermore, how to put the cursor in a position where it is possible to type bold but not blue text?

In the T_EX_MACS implementation, we were guided by the opinion that the global structure of a document is clear from its graphical appearance, and that the only place where we need more information about the structure is at the current cursor position. Consequently, the footer of the editor both displays the physical and logical properties of the text at the current position. To a lesser extent, the shape and color of the cursor itself indicate some structural properties.

As to the cursor movement, T_EX_MACS implements a graphically natural (and not structurally natural, like many other wysiwyg technical editors) cursor movement. In other words, if you press on the right arrow key, then your cursor may be expected to go to the right. More precisely, when moving the cursor around, the user modifies the position of a so called ghost cursor which may be any position on the screen. The real cursor is chosen as close as possible to the ghost cursor, in a way that “makes sense”.

Moreover, the cursor position is determined by an and a coordinate as well as an infinitesimal horizontal -coordinate, which allows the user to position the cursor in a very precise way in presence of structural markup. The figure below illustrates the use of this coordinate in the above example of bold blue text. We start with the cursor being positioned after the ‘e' in ‘Some' and show what happens if one pushes thrice the cursor key ‘'.

Similarly, the following figure illustrates what happens when the cursor is initially positioned after the ‘u' in ‘blue:

4.Additional features of TeXmacs

Let us now briefly mention some additional features of T_EX_MACS, which are not related so to say to structured wysiwyg editing, but which do make the system interesting in comparison with similar existing software.

4.1.Computer algebra systems

It is reasonably easy to interface a computer algebra system with T_EX_MACS. Such interfaces already exist for the systems Pari GP, Macaulay 2 and Gtybalt. More interfaces are currently under development. In this context, T_EX_MACS can both be used as a graphical front-end to the computer algebra system and as a text editor, which enables the user to directly include the results of his computations in an article.

The objective that it should be possible to interface T_EX_MACS with computer algebra systems has some repercussions on its design. For instance, formulas should have semantics in a natural way. We adopted the strategy that an intelligent parser should be able to assign a semantics to a formula. For this reason, we demand the user to explicitly type the multiplication symbol, since in the T_EX formulas

$a(b+c)$ $f(b+c)$

it is not clear a priori when we implicitly understand a multiplication to be present. Another problem when interfacing T_EX_MACS with a computer algebra system is that automatically generated formulas should be typeset in a satisfactory way. This necessitates new hyphenation techniques, which are still under development.

4.2.Typesetting innovations

It is often believed that T_EX is the ultimate program for professional typesetting. Indeed, T_EX_MACS incorporates many techniques from T_EX. Nevertheless, there are a few points where we think that we made useful innovations:

• We use a global algorithm for page breaking.

• Consecutive lines, such that the upper line descends to much downwards and the lower line ascends to much upwards (at different places), are “crunched together” as far as possible.

• T_EX_MACS both supports vertical space before and after a paragraph; the maximum of both is taken. The vertical space between two consecutive theorems without proof is not doubled.

Several other optimizations can be foreseen and the “technical art” of electronic typesetting is fortunately not yet dead.

4.3.Extension language

In a similar way as Emacs comes with the Emacs/Lisp extension language, T_EX_MACS provides Guile/Scheme as an extension language. At the moment, the extension language is mainly useful for programming the keyboard shorthands and the menus of the user interface. We also implemented regions of text with an associated scheme program, which is executed each time one clicks on the region.

In the future, other extension languages like Python or Caml might be supported. We also plan to use them for other purposes, like executable markup (similar to Java scripts). Executable markup may actually occur in several ways: as scripts, as formulas in a spreadsheet, or as executable enhancements of a style file.

5.Conclusion

We hope that the present paper (or, even better: the actual T_EX_MACS program) convinced the reader that structured wysiwyg editing of mathematical texts is possible and desirable. A careful analysis of the psychological factors that lead to the rejection of (structured) wysiwyg editors in the past makes it possible to eliminate these drawbacks in the future. Despite a few temporary shortcomings (mainly speed), T_EX_MACS presently shows that it indeed possible to efficiently edit structured documents in a wysiwyg manner.

Actually, we conjecture that, within five years, most mathematicians, physicists, computer scientists, etc. will use wysiwyg editors to write their documents. Furthermore, such wysiwyg editors may grow into real “technical office platforms”, capable of producing and visualizing documents or web pages, and interacting with computer algebra systems and numerical analysis programs.

In our opinion it is important that such tools can be used freely by scientists and others. In this light, T_EX_MACS is not just a structured wysiwyg editor: it is also a free editor. The fact that T_EX and L^AT_EX are free programs made it possible to share knowledge about techniques for beautiful and efficient electronic typesetting, and many people contributed to their development with pleasure. This has been a good tradition: we have to ensure that the benefits of T_EX and L^AT_EX will live and honor the scientific tradition of free exchange by carrying it on.

P.S.: the present document was written using T_EX_MACS.
